36v 12ah battery pack

32700 36v 38.4v 12ah Rechargeable Lifepo4 Ebike Battery Pack over 1500 Cycle Time

POEAE-L-306
Delivery
EXW
minimum order
1 piece
Country of Origin
China
Stock Time
5-22Day
Quantity:
US $94.57 - US $98.25 / piece
Contact Now
add to cart



  ITEM  SPECIFICATION  REMARK
  Nominal Voltage  38.4V
  Nominal Capacity  12Ah  Standard  discharge  at 0.2C
  Charge Current  0.2C ~0.5C


  Work Current  5A
  Peak Current  15A  Last time ≤1S
  Charge Voltage  43.2V
  Cycle Life  ≥1500 times until 70% capacity
  Ref. Discharge Cut off Voltage  30.0V
  Battery Cell Model  32700   6000mAh
  Configuration  12S2P
  Size  L*W*H=198*133*77mm  With PCM
  Connector/Terminal  JST connector  /customized
 OEM & ODM Support
  Battery PCM Function  Over charge/discharge,over current,        short circuit protection
  Weight  Approx. 3.43kg
  Charge Temperature Range  0°C to 45°C
  Discharge Temperature Range  -20°C to 60°C
  Recommended Storage Temperature  23 ± 5°C
  Battery Warranty  18 months


              Main Feature of this 36v 12ah ebike battery:
                【HIGH QUALITY PCM】Use customized PCM.
                 【LIGHT Power】36v 12ah ebike battery has extremely high discharge rates and supports fast charging .
                 【RELIABLE GRADE A CHINA CELLS】 We choose only high end cells even it's a China brand,performance is good ,very safe
                    but price is more competitive.
                 【18Months WARRANTY】 If 36v 12ah ebike battery ​has quality problem within 18 months,we can help fix or send new one for
                     free,you don't need to worry about after sales problem.
                 【CUSTOMIZED & SAVE TIME】 Battery cells,size,capacity ,voltage,connector... most parameters can be changed according to
                     your  request .You don't need to take too much time to search an exist model .

             Typical application



                            This series of 22.2v and above lithium batteries can be widely used in:

                      * Military flashlights

                      * Electrical equipment

                      * Solar system

                      * Golf trolley cart

                      * Electric vehicles

                      * Portable test instrument ,etc.











      1.Q:Are you really factory or just trade company?

                         A: We are factory, founded in 2007, if you don’t believe our words, we can show you a live video.

                      2.Q: How long is the warranty time?

                         A: Warranty time is 12 months for Li-ion/li-polymer battery and 18 months for LiFePO4 battery.

                     3.Q: Do you accept OEM or ODM order  ?

                         A: Yes,absolutely.We can provide customized battery according to customer's requirement .

                      4.Q: How’s your leadtime?

                          A: 2-5 days for samples, 15-25 days for mass production. If it’s special model or complex design, leadtime will be longer.

                      5.Q:Is it OK to print my logo on it?

                         A: Yes, as long as you provide authorization to us, we will print logo on battery.

                      6.Q: What’s the payment terms?

                          A: Sample fee should be 100% prepaid. For mass production, payment terms is 30% deposit, 70% balance to be paid before

                               shipment. For big amount, we can discuss better payment terms for you after 2-3 orders.

               Contact us to know more details about price, customize solution ,discount ,etc.
